Autonics TC4S Specifications

General

Dimensions	48 x 48 mm
Display Accuracy	±0.3% FS ±1 digit
Sampling Period	100 ms
Mounting	Panel mount
Control Method	ON/OFF control, P control, PI control, PD control, PID control
Input Type	Thermocouple, RTD
Power Supply	100-240VAC~ 50/60Hz
Output Type	Relay, Current
Display	7-segment LED
Operating Ambient Temperature	-10 to 50°C
Resolution	0.1°C or 1°C
Storage Temperature	-20 to 60°C (with no icing)
