1. GENERAL INFORMATION
1. DISPLAY
3. BACK BUTTON
5. LED INDICATORS
2. ROTARY KNOB
4. QUICK BUTTON
1.1. DISPLAY
• While in sleep mode:
o display is inactive;
o screensaver shows:
─ temperature;
─ current time and date;
─ set operation mode, if active.
Control panel goes in to sleep mode after the time of inactivity set
in display settings.
Sleep mode is cancelled by pressing any button or turning the knob either direction.
• While active display shows:
o current time;
o power supply voltage;
o temperature;
o set operation mode, if active;
o active timers.
To access the main screen control panel has to be woken from sleep
mode.
For air heaters temperature displayed depends on the temperature sensor
selected.
For liquid heaters temperature of the coolant is displayed.
Description of each symbol and screen layouts can be found in their respective
sections of the manual.
