Operation
Functionality of the charger
The charger automatically recognizes the connected battery type, 6V or
12V battery.
If the battery terminal clamps
4
and/or
5
are incorrectly connected (re-
verse polarity), the error indicator
13
will illuminate in red (see Fig.B). If the
charger overheats or short circuits during operation, the error indicator will
illuminate in red. The charger switches to the standby mode
14
(see Fig.C).
The charging process only starts when a charging program was selected with
the mode button
6
.
If a 6V battery is connected, only the 6V charging program
10
can be acti-
vated with the mode button. Other settings are not possible with this charging
program.
If the charger recognizes a connected 12V battery, the mode button can be
used to select between the motorcycle
7
, car
8
and cold
9
charging
programs.
The selected charging program, the current battery voltage
15
and the
charge level of the battery are shown during the charging process. As long as
the charging process is active, the frame around the battery symbol will blink
on the display
1
(see Fig.E).
Display indicators
Indicator Status
Motorcycle charging
program
7
is shown.
The motorcycle charging program for 12V
batteries with 1.2Ah~120Ah is selected.
Car charging program
8
is shown.
The car charging program for 12V batteries
with 1.2Ah~120Ah is selected.
Cold charging program
9
is shown.
The cold charging program for 12V batteries
with 1.2Ah~120Ah is selected.
6 V charging program
10
is shown.
The 6 V charging program for 6 V batteries
with 1.2Ah~14Ah is selected.
The bars for the battery charge
level
11
are partially full and
the frame is blinking.
The battery is charging.
The bars for the battery charge
level
11
are full and the frame
is displayed continuously.
The battery is fully charged.
