autoXS EA-2138 - Understanding Available Charging Programs

Operation
14
The power indicator
12
flash-
es in green, the display
1
is
blinking.
The charger is connected to the power
grid. The battery terminal clamps
4
and
5
are not connected or are not correctly
connected.
The power indicator
12
is per-
manently illuminated in green.
The charger is connected to the power grid.
The battery terminal clamps
4
and
5
are connected.
The error indicator
13
lights
up in red.
The battery terminal clamps
4
and
5
are incorrectly connected (reverse polarity).
There has been a short circuit. The charger
will switch to standby mode
14
.
The charger is overheated. It switches to
standby mode.
Standby mode
14
is shown.
The charger is in standby mode.
Voltage indicator
15
displays
a value.
The voltage indicator displays the current
voltage for the connected battery.
The voltage indicator
15
shows
ѡrr
.
The battery is not suitable or defective.
The voltage indicator
15
blinks.
The battery is reactivated with an impulse
charge.
Charging programs
The charger has four charging programs.
• Motorcycle charging program
7
: Suitable for 12V batteries with a rated
capacity of 1.2Ah to 120Ah. The battery is charged with a limited charging
current of 0.8A.
• Car charging program
8
: Designed for normal 12V car batteries with a
rated capacity of 1.2Ah to 120Ah. The battery is charged with an elevated
charging current of 3.8A.
• Cold charging program
9
: Suitable for charging normal 12V car batteries
with a rated capacity of 1.2Ah to 120Ah at low temperatures below 32°F
(0°C). The battery is charged with an elevated charging voltage and a high
charging current of 3.8A.
• 6V charging program
10
: Special program for charging 6V batteries with
a rated capacity of 1.2Ah to 14Ah. The adapted charging current amounts to
0.8A.
