HART CMD Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 22
18. HART CMD Menu
The HART CMD (Command) Menu allows the operator to perform
diagnostic and service functions as follows:
1) Self Test Internal tests are performed and any detected problems
are reported in “Status Info”.
2) Master Reset This function re-initializes the microprocessor, resets
the operating software, and initiates a hardware reset for both the
sensor and the HART interface. Latched relays are reset.
3) Loop Test This test allows the operator to manually set the analog
signal output (4 to 20 mA) to a fixed user defined value.
19. Device Setup Menu
This menu allows various setup, configuration and calibration
functions. When Write Protect is off, these menus allow the operator
to reconfigure or write new variables to the device.
1) Configuration Menu
2) Calibration Menu
3) Write Protect
4) HART Setup
5) Set Real Time Clock
Refer to the appropriate sub-menus for details.
