AUX-Light CAC 50Hz R410A Trouble shooting
103
AL-H48/5R1D(U), AL-H60/5R1D(U)
NO.
Parts No.
Chinese name
Parts name
Quantity
1
立柱
Stand column
1
2
顶盖板
Top cover
1
3
冷凝器总成
Condenser assembly
1
4
电机架
Motor support
1
5
大面板
Big panel
1
6
网罩
Grille
1
7
轴流风叶
Axial flow fan
2
8
小挖手
Handle care
3
9
室外电机
ODU fan motor
2
10
小面板
Small panel
1
11
压缩机及附件
Compressor
1
12
底盘组件
Base pan assembly
1
13
截止阀 3/8 inch
Stop valve
1
14
截止阀 3/4 inch
Stop valve
1
15
右侧板
Right side panel
1
16
阀板
Valve board
1
17
电器盖板
E-parts cover
1
18
回气管
Suction pipe
1
19
气液分离器
Gas-liquid separator
1
20
四通阀管路组件
4way assembly
1
21
电器总成
Electric box assembly
1
21.1
控制板
Main PCB
1
21.2
变压器
Transformer
1
21.3
交流接触器
Relay contact
1
21.4
风机电容 3.5μF
Fan capacitor
1
21.5
端子板
Terminal Block
1
22
隔风立板
Barrier
1
23
冷凝器固定板
Condenser bracket
1
