AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
54
13
ALCe-H24B4/C5 左挂架
Left suspend plate
1
14
ALCe-H18A4/C5 背板
Chassis welding
assembly
1
15
风轮 φ145×190×φ12
fan
2
16
ALCe-H18A4/C5 电机固定板
Volute fixing board
1
17
直流电机 FP40A-ZL(12 轴径)
motor
1
18
DR-120N/DC5-A 电控盒盖
The electronic
control box cover
1
19
CJ 控制板
DCZ-OXNX-SN1T1(18-60)K-SYE
PCB board
1
20
CJ 控制板
DCZ-OXNX-SNPOWER-C-SYE
PCB board
1
21
上涡壳 ALCe-H24B4/C5(白色)
Volute assembly
2
22
下涡壳 ALCe-H24B4/C5(白色)
Volute assembly
2
23
ALCe-H24B4/C5 右挂架
Right suspend plate
1
24
ALCe-H24B4/C5 右泡沫(开模)
Right foam
1
25
ALCe-H24B4/C5 右侧板组件
Right side panel
assembly
1
26
ALCe-H24B4/C5 右盖板
The Right side
covers
1
27
ALCe-H18A4/C5 集水盘固定板组件
Draining tray fixed
plate
1
28
ALCe-H18A4/C5 集水盘组件
Draining tray
1
29
步进电机 35BYJ46-QC120
Step motor
1
30
ALCe-H24B4/C5 显示盒组件
Display board cover
1
31
(ROHS)步进电机 35BYJ46-QC50
Step motor
1
