AUX ALCA-H**R1AA User Manual

AUX-Light CAC 50Hz R410A Sensor resistance table
155
Part 6. Sensor resistance table
Coil and environment temperature sensor 5K3470 resistance reference table
Coil and environment temperature sensor 5K3470
Tx(℃)
Average (KΩ)
Tx(℃)
Average (KΩ)
Tx(℃)
Average (KΩ)
-20
72.99
21
5.854
61
1.421
-19
35.16
22
5.626
62
1.376
-18
33.43
23
5.408
63
1.334
-17
31.80
24
5.199
64
1.293
-16
30.26
25
5.000
65
1.254
-15
28.80
26
4.811
66
1.215
-14
27.42
27
4.630
67
1.179
-13
26.12
28
4.456
68
1.143
-12
24.88
29
4.291
69
1.109
-11
23.71
30
4.132
70
1.076
-10
22.60
31
3.980
71
1.044
-9
21.55
32
3.835
72
1.013
-8
20.56
33
3.695
73
0.9837
-7
19.61
34
3.562
74
0.9550
-6
18.72
35
3.434
75
0.9273
-5
17.87
72
3.311
76
0.9005
-4
17.06
37
3.193
77
0.8746
-3
16.30
38
3.081
78
0.8496
-2
15.57
39
2.972
79
0.8254
-1
14.88
40
2.869
80
0.8021
0
14.23
41
2.769
81
0.779
1
13.60
42
2.673
82
0.758
2
13.01
43
2.581
83
0.737
3
12.45
44
2.493
84
0.716
4
11.91
45
2.409
85
0.696
5
11.40
46
2.307
86
0.677
6
10.92
47
2.249
87
0.658
7
10.46
48
2.174
88
0.641
8
10.02
49
2.102
89
0.623
9
9.596
50
2.032
90
0.606
10
9.197
72
1.965
91
0.590
11
8.817
52
1.901
92
0.574
12
8.454
53
1.839
93
0.559
13
8.108
54
1.780
94
0.544
