AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
13
Model
Indoor Unit
ALCA-H48/5R1AA
ALCA-H60/5R1AA
Panel
MB12
MB12
Outdoor Unit
AL-H48/5R1D(U)
AL-H60/5R1D(U)
Factory Model
Indoor Unit
ALCa-H48A5/R1EB-B7
ALCa-H60A5/R1EB-B7
Panel
MB12
MB12
Outdoor Unit
AL-H48A5/R1(T)-B7
AL-H60A5/R1(T)-B7
Code
Indoor Unit
16106022000057
16106022000058
Panel
16108002000007
16108002000007
Outdoor Unit
16107022000022
16107022000023
Power Supply
V~,Hz,Ph
380~415,50,3
380~415,50,3
Capacity
Cooling
Btu/h
48000
60000
kW
14.00
17.60
Heating
Btu/h
53000
63500
kW
15.50
18.50
Electric Data
Rated Cooling Power
Input
kW
4.87
5.71
Rated Heating Power
Input
kW
5.13
6.00
Rated Cooling Current
A
8.88
10.42
Rated Heating Current
A
9.33
10.88
Performance
EER
W/W
2.87
3.08
COP
W/W
3.02
3.08
Indoor Fan Motor
Model
XD80A
XD80A
Brand
WELLING/Sinjun
WELLING/Sinjun
Output Power x Fan
Quantity
W
80*1
80*1
Capacitor
uF
3
4
Speed (Hi/Mi/Lo)
r/min
695/585/495
695/585/495
Indoor Coil
Number Of Rows
2
3
Tube Pitch(a)x Row
Pitch(b)
mm
20.5×12.7
20.5×12.7
Fin Pitch
mm
1.4
1.4
Fin Material
Hydrophilic aluminum fin
Tube Outside Dia.and
Type
mm
φ7 Inner grooved
φ7 Inner grooved
Coil Length x Height x
Width
mm
2142×246×25.4
2142×246×25.4
Heat Exchanging Area
m
2
15.60
15.60
Indoor Unit
Indoor Air Flow
(Hi/Mi/Lo)
m
3
/h
1800/1440/1260
1800/1440/1260
Noise Level(Hi/Mi/Lo)
dB(A)
50/47/41
50/47/41
Net Dimension
(W*H*D)
mm
835×835×290
835×835×290
