AUX ALCA-H**R1AA User Manual

AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
34
ALCA-H24/4R1AA, ALCA-H36/4R1E ,ALCA-H36/5R1AA, ALCA-H48/5R1AA，ALCA-H60/5R1AA
No.
Materiel No.
Chinese name
Part Name
Quantity
1
钣金套件
Sheet metal Assembly
1
1.1
围板 A
Cabinet A
2
1.2
围板 B
Cabinet B
1
1.3
围板 C
Cabinet C
1
1.4
底盘组件
Chassis assembly
1
1.5
挂钩
hook
4
1.6
压线扣
Wire fastener
5
1.7
电机线固定板
Power line fixed plate
1
2
阀板
Valve plate
1
3
塑料排水软管
Drain pipe
1
4
塑料排水软管
Drain flexible pipe (Drain pump)
1
5
底盘泡沫组件
Chassis foam assembly
1
6
水泵支架
Drain pump support
1
7
排水泵
Drain pump
1
8
浮子开关
Float switch
1
9
蒸发器挂钩(喷涂)
Evaporator hook
3
10
蒸发器总成
Evaporator assembly
1
10.1
蒸发器组件
Evaporator assembly
1
10.2
蒸发器进液管组件
Evaporator inlet tube assembly
1
10.3
蒸发器出气管组件
Evaporator outlet tube assembly
1
11
电机
Fan motor
1
12
风轮
Fan
1
13
接水盘组件
Drain pan assembly
1
14
导风圈
Guide wind loop assembly
1
15
电控盒总成
Electric box assembly
1
15.1
电控盒
Electric box
1
15.2
控制板
PCB board
1
15.3
变压器
Transformer
1
15.4
风机电容
Capacitor
1
15.5
端子板
Terminal Block
1
16
电控盒盖
Electric control box cover
1
17
面板
Panel Assembly
1
17.1
边角盖板
Corner Cover
1
17.2
过滤网
Air Filter
1
17.3
围框
Cabinet
1
17.4
回风格栅
Air Inlet Grilling
1
17.5
步进电机
Step motor
1
18
风叶网罩
Mesh
1
