AUX ALCA-H**R1AA User Manual

AUX Light Commercial Air Conditioners T1,50Hz, R410a,ON/OFF
39
Model
Indoor Unit
ALCF-H36/4R1
ALCF-H36/5R1C
Outdoor Unit
AL-H36/4R1(U)
AL-H36/5R1D(U)
Factory Model
Indoor Unit
ALCe-H36A4/R1-C5
ALCe-H36A5/R1C5-B7
Outdoor Unit
AL-H36A4/R1(T)
AL-H36A5/R1(T)-B7
Factory Model
Indoor Unit
16209005000008
16109022000008
Outdoor Unit
16107022000001
16107022000020
Power Supply
V~,Hz,Ph
220~240,50,1
380~415,50,3
Capacity
Cooling
Btu/h
36000
36000
kW
10.6
10.6
Heating
Btu/h
37500
40000
kW
10.9
11.7
Electric Data
Rated Cooling Power
Input
kW
3.52
3.77
Rated Heating Power
Input
kW
3.45
3.50
Rated Cooling Current
A
17
6.76
Rated Heating Current
A
16.5
6.28
Performance
EER
W/W
2.81
2.81
COP
W/W
3.34
3.34
Indoor Fan Fotor
Model
YSK-70W-4
YSK-70W-4
Brand
HUATE
Weiling
Output Power x Fan
Quantity
W
70
70x1
Capacitor
uF
4
4
Speed (Hi/Mi/Lo)
r/min
1386/ 1108/ 970
1386/1108/970
Indoor Coil
Number Of Rows
3
3
Tube Pitch(a)x Row
Pitch(b)
mm
20.5×12.7
22×19.05
Fin Spacing
mm
1.6
1.6
Fin Material
louver
Hydrophilic aluminum fin
Tube Outside Dia.and
Type
mm
φ7,Inner grooved
φ7.94,Innergrooved
Coil Length x Height x
Width
mm
950×242×38.1
950×242×57.15
Heat Exchanging Area
m
2
8.89
15.02
Indoor Unit
Indoor Air Flow
(Hi/Mi/Lo)
m
3
/h
1500/1200/1050
1500/1200/1050
Noise Level(Hi/Mi/Lo)
dB(A)
50/47/41
50/47/41
Net Dimension
(W*H*D)
mm
1280×660×205
1280×660×205
Packing Dimension
(W*H*D)
mm
1360×720×290
1360×720×290
