AUX-Light CAC 50Hz R410A Trouble shooting
85
Type/Quantity
Charged Volume
g
800
1250
1400
Design Pressure
MPa
4.4
4.4
4.4
Refrigerant
Piping
Liquid Side
mm
6.35
6.35
9.52
Gas Side
mm
12.7
12.7
15.88
Max. Length
m
15
20
30
Max. Height
m
10
15
15
Setting Temperature Range
°C
16~32
16~32
16~32
Operation
Temperature Range
Cooling
°C
-15~49
-15~49
-15~49
Heating
°C
-15~24
-15~24
-15~24
Application Area
m
2
13-21
21-35
28-47
Connection
Wiring
Power Wiring(Indoor)
mm
2
3×2.5mm
2
3×2.5mm
2
/
Power Wiring(Outdoor)
mm
2
/
/
3×6mm
2
Signal Wiring
mm
2
3×2.5mm
2
+2×1mm
2
3×2.5mm
2
+2×1mm
2
3×2.5mm
2
+3×1mm
2
Stuffing
Quantity
20/40/40H
Unit
102/219/292
102/219/292
96/198/198
Notes:
1. Nominal cooling capacities are based on the following conditions: Return air temp.: 27°CDB, 19°CWB,
and outdoor temp.: 35°CDB, 24°CWB;
2. Nominal heating capacities are based on the following conditions: Return air temp.: 20°CDB, and
outdoor temp.: 7°CDB, 6°CWB;
3. Parameters above are all measured when the connecting pipe is 5 meters.
