AUX ALCA-H**R1AA User Manual

AUX-Light CAC 50Hz R410A Trouble shooting
87
Design Pressure
MPa
4.4
4.4
Refrigerant
Piping
Liquid Side
mm
9.52
9.52
Gas Side
mm
15.88
15.88
Max. Length
m
50
50
Max. Height
m
30
30
Setting Temperature Range
°C
16~32
16~32
Operation
Temperature Range
Cooling
°C
-15~49
-15~49
Heating
°C
-15~24
-15~24
Application Area
m
2
42-70
42-70
Connection
Wiring
Power Wiring(Indoor)
mm
2
3×4mm
2
3×1mm
2
Power Wiring(Outdoor)
mm
2
5×4mm
2
5×4mm
2
Signal Wiring
mm
2
2×1mm
2
2×1mm
2
Stuffing
Quantity
20/40/40H
Unit
60/126/126
60/126/126
Notes:
1. Nominal cooling capacities are based on the following conditions: Return air temp.: 27°CDB, 19°CWB,
and outdoor temp.: 35°CDB, 24°CWB;
2. Nominal heating capacities are based on the following conditions: Return air temp.: 20°CDB, and
outdoor temp.: 7°CDB, 6°CWB;
3. Parameters above are all measured when the connecting pipe is 5 meters.
Model
AL-H48/5R1D(U)
AL-H60/5R1D(U)
Factory Model
AL-H48A5/R1(T)-B7
AL-H60A5/R1(T)-B7
Code
16107022000022
16107022000023
Power Supply
V~,Hz
,Ph
380~415,50,3
380~415,50,3
Max. Input Consumption
W
5950
7800
Max. Current
A
13.50
16.50
Capacity
Cooling
Btu/h
48000
60000
kW
14.07
17.58
Heating
Btu/h
53000
63500
kW
15.50
18.50
Compressor
Model
ATE498SC3Q9RK1
ATE590SC3Q9JK
Type
Twin Rotary
Twin Rotary
Brand
HIGHLY
HIGHLY
Capacity
W
12650
14850
Input
W
4130
4950
Rated Current(RLA)
A
7.2
8.7
Locked Rotor Amp(LRA)
A
69
65
Thermal Protection temp.
160
180
Capacitor
uF
/
/
Refrigerant Oil
ml
1600
1850
Outdoor Fan
Model
YDK60-6H
YDK60-6H

AUX ALCA-H**R1AA Specifications

General

Brand	AUX
Model	ALCA-H**R1AA
Category	Air Conditioner
Language	English
