AUX F Series User Manual

AUX DC Inverter Free Match 50HZ R32
130
For example:
If you changed a new PCB to 18K cassette indoor unit , then you should set the type of the
unit , check the above【Parameter Setting Items table】--- Mode of IDU is 【04】， 18K cassette
parameter is 【37】
2.3 Parameter Setting by XK-04/ XK-05
Parameter checking
Press the “FUNCTION” button for 5 seconds; enter into the parameter checking interface.
the wired controller’s address will be displayed in the temperature zone of LED screen (press
“FUNCTON” button, the wired controller’s address will flash, the wired controller‘s address can
be changed through press the“ ”or“ ”, then press “FUNCTION” button to confirm);
Change to 【04】
Change to 【37】，then press【Mode】to confirm

AUX F Series Specifications

General

Refrigerant	R410A
Energy Efficiency Class Cooling	A
Power Supply	220-240V, 50Hz
Type	Split
Features	Auto Restart, Sleep Mode
Warranty	1 Year
