AUX F Series User Manual

AUX DC Inverter Free Match 50HZ R32
156
No.
Chinese Name
Part Name
Part Code
Qty
1
面板
Panel
11320003002880
1
2
显示灯板
Display board
11222014000608
1
3
导风门
Air louver
（
Horizontal
）
11320005000360
1
4
过滤网
Filter
11220508000145
2
5
螺钉盖
Screw cover
11320096000102
3
6
中框接线盖
Medium frame wiring cover
11320076000105
1
7
中框装饰板
Medium frame decorating plate
11320088000039
1
8
中框组件
Medium frame assembly
11220501000778
1
8.1
左端盖
Left panel
11320078000161
1
8.2
中框
Medium frame
11320002000293
1
8.3
右端盖
Right panel
11320078000162
1
9
蒸发器总成
Evaporator assembly
11224003000820
1
9.1
蒸发器左支架
Evaporator left side carriage
11320015000123
1
9.2
蒸发器部件
Evaporator assembly
11224009000214
1
9.2
蒸发器部件
Evaporator assembly
11224009000213
1
9.3
蒸发器护套
Evaporator protecting bush
11320101000018
1
10
轴承固定座
Bearing fixed chassis
11320062000026
1
11
轴承组合件
Bearing assembly
11220551000003
1
12
贯流风叶
Cross flow fan
11220513000059
1
13
底座组件
Chassis assembly
11220500000289
1

AUX F Series Specifications

General

Refrigerant	R410A
Energy Efficiency Class Cooling	A
Power Supply	220-240V, 50Hz
Type	Split
Features	Auto Restart, Sleep Mode
Warranty	1 Year
