AUX F Series User Manual

AUX DC Inverter Free Match 50HZ R32
159
No.
Chinese Name
Part Name
BOM Code
Qty
1
面板
panel
16108022000017
1
1.1
导风门轴套
Shaft bushing of damper
16420009000009
1
1.2
回风格栅
air return grille
16420010000033
1
1.3
步进电机
Motor Assembly
16320005000042
4
1.4
导风条
Guide the wind vane
16420007000035
4
1.5
过滤网
Filter net
16420012000012
1
1.6
围框
panel frame
16420013000072
1
1.7
电机盖板
Electric cover plate
（
no air
outlet）
16420014000041 2
1.8
电机盖板
Electric cover plate
16420014000040
2
2
电控总成
Electric board Assembly
16321005000024
1
3
电控盒
electric control box C
16421038000328
1
4
导风圈
Guide solar or lunar halo
ABS-FR
16420004000008 1
5
接水盘
drain pan
16320005000039
1
6
过线夹
clamp
16420021000010
1
7
风轮
wind wheel
16444001000037
1
8
压线板
pressing line plate
16421008000022
1
9
电机
Fan motor
16430001000638
1
10
蒸发器总成
Evaporator assembly
（
09/12
）
16324005000087
1
蒸发器总成
Evaporator assembly
（
18
）
16324005000081
1
11
排水泵
draining pump
16440001000020
1
12
地盘泡沫组件
Chassis foam unit
16320005000038
1
13
围板
B
Coaming B
16421010000072
1
