3.4 Drainage Checking
In case of maintenance, remove grille from casing of the unit according to the following
procedures:
◇ As shown in right diagram, remove two screw caps on both sides of the front grille and then
screw down two fixing screws.
◇ Pull the lower end of grille cover towards oneself to remove it.
◇ Reinstall grille cover, then install the grille cover to proper position according to the reverse
sequence of the above.
◇ Pour a glass of water into plastic drainage groove;
◇ Confirm if the water flows through the drainage outlet of indoor unit.

AUX F Series Specifications

General

Refrigerant	R410A
Energy Efficiency Class Cooling	A
Power Supply	220-240V, 50Hz
Type	Split
Features	Auto Restart, Sleep Mode
Warranty	1 Year
