AUX L Series User Manual

AUX DC Inverter Free Match 50HZ R32
67
Piping
Liquid Side
mm(inch)
4×6.35(1/4)
5×6.35(1/4)
Gas Side
mm(inch)
4×9.52(3/8)
5×9.52(3/8)
Max. length for
all rooms (m)
m
80 80
Max. length for
one IU (m)
m
35 35
Max. height
difference
between IU and
OU (m)
m
15 15
Max. height
difference
between IUs (m)
m
10 10
Ambient Temp (Cooling/Heating)
℃
-15~52/-15~24
℃
-15~52
℃
/-15~24
℃
Stuffing
Quantity
20/40/40H unit 44/96/144 44/96/144
Note:
1. Cooling capacity test Condition:(27℃DB,19℃WB Indoor/35℃DB,24℃WB Outdoor);
Heating capacity test Condition:(20℃DB Indoor/7℃DB,6℃WB Outdoor);
Connecting pipe length: 7.5M.
2. Data may be changed with unit improvement. We keep the right to change the data or
specifications without prior notice, please follow the data listed on the nameplate.
