SYSTEM FEATURES –
Values marked with ( ) are the factory default programming
Feature
070
Feature
071
Enable-Siren/Bell Test upon Arming
1
Enable-Erase F. Me number on Disarm
1
Enable-Keypad 3 Beeps upon Disarming
(2)
Enable-Instant Arming via Key 5
2
Enable-Buzzer upon Entry Delay
(3)
Enable-Buzzer during exit delay
3
Enable-Keypad Tactile Beep
(4)
Enable-Display Alarmed Zone during alarm
4
Disable-4 LEDs display during Armed
5
Enable-Manual Bypass via Code No .1
5
Enable-Battery Test upon Arming
(6)
Enable-Lock in Armed after Tamper Alarm
6
Reserved
7
Enable-Momentary Key-Switch
(7)
Enable-Keypad Panic
(8)
Enable-Code ‘8’ as one time code
8
Feature
072
Feature
073
Enable-Bell mode
(1)
Enable-Display troubled zones at Disarmed
(1)
Enable-Detailed alarm history
(2)
Enable-Test to central station each hour
2
Enable-Report Opening/Closing
(3)
Enable-Self contain Bell (0V at alarm) **
3
Activate ON output for ADSL filter line-cut
4
Reserved
4
Enable-Report bypassed zones at Arming
5
Enable- Group Bypass when Arm with Key
5
Enable-Exit delay when delayed zones clear
6
Enable - 2 Siren Beeps at Key Disarming
6
Enable -’ON’ output as SVM trigger *
7
Enable - A1 output time follows Siren time
(7)
Enable-codes reset to default by * & #
(8)
Enable - Outputs (A1, ON) 0V at active
8
Feature
074
Feature
075
Reserved
1
Enable – K. Pad & Sir sounds @ Home mod
1
Enable-Activate A1 via DTMF
2
Enable – 2048 New Zones Wiring Method
2
Enable-Auto reset zone after alarm timeout
3
Reserved
4
Enable – Zone at 032 “Very slow zone”
4
Reserved
5
Enable – DTMF control (D type or Ver. 3)
(6)
Enable – Bypass Answer Machine
7
Enable-Echo Cancellation Tone (AUSTEL)
8
Enable - A1 output as Latching
8
* AV-2004D starting January 2005. ** Self-contained Bell is operative if Bell mode selected

DIAL PARAMETERS
Pre-Dial
Delay
Wait
for Dial
Tone
Anti-Jam
Delay
Dial tone
detection
Dial
Mode
Tel.
MSG
Time
Inter-
Call
Delay
Re-Dial
Cycles
(max.)
Pulse
MAKE
Pulse
BREAK
Inter
Digit
Delay
Rings
qut'y for
modem
Instant
modem
answer
Ring
Cycle
Width
Sec's
Sec's
Sec's
00=No
01=Yes
0=Pulses
1=DTMF
Sec's
Sec's
XX Cycle
5 mS
5 mS
50 mS
Tel.
Rings
00=No
01=Yes
100 mS
(1-25)
080
081
082
083
084
085
086
087
088
089
090
091
092
093
0
3
0
4
1
0
0
1
0
1
5
0
2
0
0
3
0
8
1
2
2
0
1
0
0
1
2
0
Tel.
Line
Test
Intervals
Min.
Ring
Length
Rings
Time
Out
Minutes
(Max 99)
10 mS
(Max 20)
Seconds
(4 to 25)
094
095
096
0
0
1
5
0
6
Note address 091: The download is ENABLED by default. Setting 21 at address 091 disable modem (because 21 rings for modem not accepted by
telephone net). To ENABLE enter 01 to 20 at address 091. For Instant Modem Answer (Answer Now): Enter 01 in address 092, hold-down key 6
then hold-down key 1, ‘A’ displayed in confirmation. For special application, address 093 set the ring detector pulse width.

SET USER CODES:
Address 099 provides setting of user codes 1 to 8.

SET FACTORY DEFAULT:
In address 200 enter 6 9, program will revert to factory default programming
