38
COMMUNICATOR PARAMETERS
Telephone Receiver Reserved Handshake
Data
Format
Protocol Sum
Check
Transmit Internal MSG Wait for
Format Frequency
Type (Parity) Rounds Time Handshake
No. 2 201 203 205 207 209 211 213 215
0 0 0 1 0 2 0 0 0 1 0 0 3 0 2 0
Telephone Receiver Handshake
Data
Format
Protocol Sum
Check
Transmit Internal MSG Wait for
Format Reserved Frequency
Type (Parity) Rounds Time Handshake
No. 3 202 204 206 208 210 212 214 216
0 0 0 1 0 2 0 0 0 1 0 0 3 0 2 0
00 - Dialer only (No Communicator)
00=1400 Hz
00=3 X 1
00=Standard
00=None 00=2 Rnd 00=0.1 Sec XX=Sec's
01 - Ademco, Silent Knight Slow,
Scantronic
01=2300 Hz
01=4 X 1
01=Extend 01=S.Check 01=1 Rnd 30=3 Sec
02 - Radionics Fast
03 - Sescoa, Vertex, DCI, Franklin
02=Hi/Low
02=4 X 2
3 Sec's is
04 - Silent Knight Fast
Default
05 - Radionics, DCI, Franklin Slow ** 03=3 X 2
06 - Universal High Speed
07 - Contact ID/Ademco Fast
00 - ‘No Communicator,’ is identical to ‘Dialer’ that generates sound upon alarm. ** For Contact ID, program 02 in 203 & 204 address. For Ademco Fast
enter 02 at address 023 & 024. ‘Rnd’ is short for ROUNDS. ‘S. Check’ is short for ‘Sum Check.’ ‘Hz’ is short for ‘Hertz’ (frequency unit).
REPORT SELECTION (Sections 9 and 10 require no programming if Contact ID selected)
For communicator codes A to F (Hex), enter the following: A=10, B=11, C=12, D=13, E=14, F=15. Note: entering 0 0, is equal to blank.
Group 1 Group 2
Report on Alarm
105
Report on Alarm
106
1 2 3 4 5 6 7 8 ZONE AC
LB
PA
1 2 3 4 5 6 7 8
VALUE
1 2 3
Zone Restore
107
Control Panel Restore
108
1 2 3 4 5 6 7 8 ZONE AC
LB
PA
1 2 3 4 5 6 7 8
VALUE
1 2
Report Bypassed Zone
109
Reserved
110
1 2 3 4 5 6 7 8 ZONE
1 2 3 4 5 6 7 8
VALUE
ALARM, RESTORE, BYPASS ZONES, OPENING / CLOSING, SIGNAL TEST & FORCE OPENING CODES
Group 1 Group 2
Alarm Codes - Single Codes Alarm Codes - Single Codes
1 2 3 4 5 6 7 8
Z O N E S
AC
LB
PA
(Alarm Code for Fire=1)
110
112
114
116
118
120
122
124
126
128
130
3 3 3 3 3 3 3 3
CODES
F F 2
111
113
115
117
119
121
123
125
127
129
131
1 2 3 4 5 6 7 8
CODES
9 8 1
Alarm Codes - Extended or 2 Digits Alarm Codes - Extended or 2 Digits
Restore Codes - Single Codes Restore Codes - Single Codes
1 2 3 4 5 6 7 8
Z O N E S
AC
LB
PA
142
144
146
148
150
152
154
156
158
160
162
E E E E E E E E
CODES
E E E
143
145
147
149
151
153
155
157
159
161
163
1 2 3 4 5 6 7 8
CODES
9 B A
Restore Codes - Extended or 2 Digits Restore Codes - Extended or 2 Digits
To Next Page
