3. If code is valid, ‘P’ will be displayed. The two left LED's (Red & Green) blink to indicate that
system is waiting for a new programming address number.
4. Enter address to be programmed (see programming sheet). Current value of address is displayed,
and LEDs will blink.
Note: Blinking of two left-most LEDs means system is waiting for new
address
to be entered.
Enter a 3 or 2-digit address (according to address length.)
Note: Three blinking LEDs means system is waiting for new
value
to be entered;
Enter a 2-digit value, or as required.
EXAMPLE 1:
‘P’ is displayed and the two left-most LEDs are blinking.
1. Program zones 1 and 4 as ‘Exit/Entry Delayed 1’ zones.
2. Address 021 represents the ‘Exit/Entry Delayed 1’ zones.
3. Press
0
Shunt
2
Shunt
Display
1
Siren
; current value of this address is ‘1’ (default program.)
Three LEDs will blink and a ‘1’ will be displayed (default program).
4. To enter new required value, press the address number
0
Shunt
2
Shunt
Display
1
Siren
,
followed by the new value
(‘1’ and ‘4’) by pressing
1
Siren
4
Delay
Delete
in uninterrupted sequence; ‘U’ confirms programming updating.
5. ‘P’ is displayed and the two left-most LEDs are blinking.
EXAMPLE 2:
1. Program zone 8 as a 24H zone (in default, this is an Instant Zone).
2. Address 024 represents the 24H zones
3. Press
0
Shunt
2
Shunt
Display
4
Delay
Delete
; current value of the address is ‘-’ (‘-’ means blank - no 24H zone is
programmed). 3 LEDs will blink, and ‘-’ will be displayed (default program).
4. To enter new required values, press the address number
0
Shunt
2
Shunt
Display
4
Delay
Delete
,
and
then enter new value
‘8,’ by pressing
8
Program
(zone 8); ‘U’ confirms programming updating.
5. ‘P’ is displayed and the two left-most LEDs are blinking.
Note: To disable a feature, program ‘0’ in the feature’s address
EXAMPLE 3:
1. To program zone 1 to 4 as “Fast Response Zone”.
2. Address 032 represents “Fast Response Zone”.
3. Press
0
Shunt
3
Status
2
Shunt
Display
; current value of the address is blank;
3 LEDs will blink and ‘-’ will be displayed (- means blank; no Fast Response Zone is default program).
4. To Enter new required value press the address number
0
Shunt
3
Status
2
Shunt
Display
then enter new
value 1 2 3 4 by pressing
1
Siren
2
Shunt
Display
3
Status
4
Delay
Delete
.
‘U’ confirms programming updating.
5. ‘P’ is displayed, 2 left-most LEDs are blinking.
EXAMPLE 4:
1. Program Siren Time for a 2-minute duration (default 4 minutes).
2. Address 063 represents the Siren Time.
