AV-GAD EasyLoader AV-2005 - Page 48

48
3. Press
0
Shunt
6
Telephone
3
Status
; current value of the address is 04;
3 LEDs will blink and ‘04’ will be displayed (default program).
4. Enter address 063, then a new value of ‘02’ by pressing
0
Shunt
2
Shunt
Display
. ‘U’ confirms programming
updating.
5. ‘P’ is displayed and the two left-most LEDs are blinking.
EXAMPLE 5:
Enter an Exit Delay of approximately 2 minutes, by entering the value ‘30’ in address 062;
(30 seconds x 4 = 120 seconds).
EXAMPLE 6:
1. Disable Dial Tone Detection. (Used for exchanges where Dial Tone is not the standard
440 HZ tone).
2. Address 083 represents Dial Tone Detection.
3. Press
0
Shunt
8
Program
3
Status
; current value of the address is 01;
3 LEDs will blink and ‘01’ will be displayed (default program).
4. Enter to address 083, followed by the new value ‘00’ by pressing
0
Shunt
0
Shunt
; ‘U’ confirms
programming updating.
5. ‘P’ is displayed and the two left-most LEDs are blinking.
EXAMPLE 7:
1. Enable Siren Test upon Arming (in default program the siren test is disabled).
2. Address 070 represents ‘Enable Siren Test upon Arming.’
3. Press
0
Shunt
Test
7
1
Siren
; current value of the address is 2 3 4 6 8;
3 LEDs will blink and ‘2 3 4 6 8’ will be displayed (default program).
4. Enter address 071 and then enter the new value 1 2 3 4 6 8, by pressing
1
Siren
2
Shunt
Display
3
Status
4
Delay
Delete
6
Telephone
8
Program
; ‘U’ confirms programming updating.
5. ‘P’ is displayed and the two left-most LEDs are blinking.
EXAMPLE 8: Report to Central Station
Note: To enter data use two digits, i.e. in address 110 to change the transmitted code from the
default value ‘3’ to ‘5’, at keypad enter ‘0’ ‘5’ (not 5). If ‘5’ entered, an ‘E’ (Error) appears
 Enable communicator to report to central station (in default programming communicator is disabled,
and dialer is activated upon alarm). Telephones 2 and 3 (refer to program sheet) are used to
communicate to central station.
 Contact the central station to get receiver format, event codes, subscriber number, handshake
frequency (1400 or 2300 Hz), and telephone number(s). Two telephone numbers are available, Tel. 2 is
main central station Tel. Number and Tel. 3 is backup, in case Tel. 2 fails.
Do not program different formats for each telephone.
 Refer to part ‘7’ of the programming sheet. Fill in central station’s details. For example, if the
receiver format is Radionics Fast for Tel. No. 2, enter ‘02’ in address 201.
Most important parameters are the Receiver Format, Handshake frequency and Data Format.
