16
• When cleaning the Print Head, always
wipe in one direction - from left to right
only or right to left only - to prevent
excessive stress to the Print Head.
• DO NOT WIPE BACK AND FORTH - to
prevent dust and dirt on cleaning cloth
from being redeposited on the Print Head.
CLEANING DIRECTION
PRODUCT SPECIFICATIONS
SPECIFICATION
DIMENSIONS 8.98 in. L x 5.28 in. W x 6.42 in. H (228mm L x 134mm W x 163mm H)
WEIGHT 2.65 lb. (1.2 kgs)
PRINT METHOD Direct Thermal
PRINTING RESOLUTION 203 DIP (8 dots/mm)
PRINTING SPEED 2ips - up to 4ips (51-102mm/s)
PRINTING LENGTH Max. 100 in. (2540mm)
PRINTING WIDTH Max. 2.83 in. (72mm), Min. 1 in. (25.4mm)
GENERAL
• Surface of Print Head's heating element is very fragile.
• To prevent any possible damage, please use the Print Head Cleaning Pen or soft cloth/cotton
buds with Ethanol or Industry Alcohol to clean Print Head surface.
• It's strongly recommended to wear gloves during cleaning.
• DO NOT touch print head surface with bare hands or with any hard equipment
• Water should be kept away in case of corrosion on heating elements.
CLEANING MATERIAL
To keep the Print Head running efficiently, and to extend the life of the printer,
regular cleaning is needed.
NOTE: Always switch off printer power before cleaning.
It's recommended to clean Print Heads regularly, at least when changing label rolls (in direct thermal
printing mode). In addition, if printers are operated under critical applications and environments, or
if it's found that print quality is degraded, please clean print heads more frequently.
PRINT HEAD MAINTENANCE GUIDE
CLEANING INTERVAL
CARING FOR YOUR PRINTER
