Installation (for qualified installers only) 19
Travis Industries 4122104 93508117
Opening the Door
Open the latch.
With the pawl free of the
strike, the door may be
swung open.
Swing the right
panel back.
When securing the door, make sure the pawl
fits over the strike before tightening.
Strike
Pawl
Door
Frame
NOTE: Do not overtighten the pawl by screwing
it in. This will permanently damage the latch.
