Avalon Cedar EF - Optional Equipment & Addenda; LP Conversion Instructions

Optional Equipment 31
Travis Industries 4122104 93508117
LP Conversion Instructions
Install the conversion kit prior to installing the gas line to ensure proper gas use.
1 Open the door (see page 19). Remove the logs and coals (if installed - page 20)
2 Remove the burner (see illustration below).
BURNER INSTALLATION WARNING:
When replacing the burner, make sure
this “O” ring seals the burner tube to
the mixing tube.
Mixing Tube
Burner Tube
AA
AA
AA
A
A
Reach into the firebox and
lift the burner upwards.
Pull the burner forward, out
of the firebox.
This tube on the burner
inserts into this tube on the
mixing tube.
Mixing Tube
When Installing, make sure the
burner rests on this ledge inside
the firebox.
Do not lift burner out by the
pins.
