AVANT 225 - Technical Specifications; Dimensions and Key Measurements; Drive Speed and Pulling Force

Avant 220/225
23
.
Technical specifications
Dimensions
General dimensions
Length
1910 mm
225LPG: 1940 mm
Width
1025 mm (with standard tyres)
995 mm (see page 25)
Height
1880 mm (with standard tyres)
Mass (empty)
220
225
225 LPG
700 kg
700 kg
760 kg
Tyres
Standard:
20 x 8.00-10 TR /
20 x 8.00-10 GR
Lifting height
1400 mm
Max reach
810 mm
Turning radius,
inside/outside
910 mm / 2220 mm
Ground clearance
150 mm
Drive speed and pulling force
Tyre
Drive
speed
Pulling
force
220
20 x 8.00-10 TR
10 km/h
6200 N
20 x 8.00-10 GR
10 km/h
6200 N
225
225
LPG
20 x 8.00-10 TR
10 km/h
6400 N
20 x 8.00-10 GR
10 km/h
6400 N
Height and Width
Tyre
Height
Width
20 x 8.00-10 TR
1880 mm
995 mm
20 x 8.00-10 GR
1880 mm
995 mm
.
..
.
..
.
..
.
..
.
..
.
..
.
..
