755/760iDescription of the loader
Technical specification
Model AVANT 755 AVANT 760i
Length 3080 mm
Width see table on page 11
Height
(with standard wheels)
2060 mm 2110 mm
Ground clearance
252 mm 305 mm
Weight, starting from 1970 kg 2100 kg
Standard wheels 320/60-12 TR 400/50-15 TR
Transmission, drive hydrostatic
Hydraulic oil tank capacity 38 l
Hydraulic oil type ISO VG 46
Auxiliary hydraulics 80 l/min, 225 bar
Turning radius inside/outside 1240 / 2780 mm
Max. lifting height
3100 mm
Max. lifting capacity (hydr.) 2100 kg
Max. tipping load* 1400 kg
Max. breakout force / 50 cm 1700 kg
Sound
pressure
level
2000/14/EC L
P
86 dB (A)
Sound power level
2000/14/EC L
W
101 dB (A)
Hand-arm vibration, total
< 2,5 m/s²
Whole-body vibration, max. < 0,5 m/s²
*) Load is measured at 400 mm from the attachment coupling plate,
including attachment weight ( 70 kg ) and
with counterweights.
Drive speed and pulling force
Height with cab
26x12.00-12 or
320/60-12
320-55/15 400/50-15 *)
LX Cab 2078 mm 2112 mm 2132 mm
DLX
Cab
2105 mm 2139 mm 2169 mm
DLX Cab with AC on the roof 2241 mm 2275 mm 2305 mm
DLX Cab with Lightbar 2301 mm 2335 mm 2365 mm
320/60-12 and
26x12.00-12
320/55-15
400/50-15
31x15.50-15
755 Drive speed 17 km/h 19 km/h -
Pulling force 1330 kp 1240 kp -
760i Drive speed 26 km/h 27 km/h 30 km/h
Pulling force 1880 kp 1750 kp 1600 kp
Model AVANT 755/760i
Engine make and type Kohler KDI 1903 TCR
Function 4-stroke, OHV, four valves/cylinder, Tur-
bocharged, Common rail direct injection
Coolant
Water/50% antifreeze, Freezing point -37C, total 11.6l
Number of cylinders 3
Starter electric
Bore x stroke 88 x 102
Displacement 1861 cm³
Output (ECE R120) 42 kW / 56 hp
Max torque
220 Nm @ 1500 rpm
Fuel Ultra low sulfur diesel fuel
Fuel tank capacity 40 l
Engine oil type API CJ-4 / Low SAPS Euro 6
e.g. Mobil Delvac 1 LE 5W-30
Viscosity 5W-30 (0W-30 below -25 C)
Engine oil capacity Min 5 l max 8,7 l incl. oil filter
Emissions level
EU 97/68/EC Stage 3B, US EPA/CARB Tier 4 Final
Max inclination
Max intermittent 30°
Continuous operation max 25° any direction
1080 - 1450 mm
2060 - 2110 mm
3080 mm
970 mm 1500 mm 610 mm
3040 - 3100 mm
2630 - 2690 mm
252-305
700 mm
*) 760i only
