INSTALLATION
HOW TO INSTALL THE BACKSPLASH
A
Align the backsplash to rear part of the cooktop.
As shown in the diagram
B
Secure the backsplash to the cooktop from the
back using the Philips head screws provided.
As shown in the diagram
C
Secure the backsplash from the bottom using the
Philips head screws provided.
As shown in the diagram
HOW TO LEVEL THE RANGE
The range is equipped with 4 LEVELLING LEGS and may be
leveled by screwing or un-screwing the feet with a spanner tool.
Note:
Models GRO20P0W / GRO24P0W:
There are two leveling legs at the rear of the unit.
The front feet cannot be adjusted.
