INSTALLATION
ANTI-TIP STABILITY DEVICE INSTALLATION INSTRUCTIONS
1.
The anti-tip bracket has to be attached as shown on figure below (only rear right
side), it has to be fixed on the floor and on the rear wall by four (4) suitable
screws (not supplied).
2.
After fixing the anti-tip bracket, slide range into place. Be sure the rear right foot
slides under the anti-tip bracket attached.
YOU MUST USE T H E
ANTI-TIP / STABILITY
BRACKET TO PREVENT
UNIT FROM TIPPING.
