Avantree Quartet - Page 10

User Manual
Quartet
8
EN
STEP 2
Check the transmitter’s audio signal indicators and ensure that “OPT” is lit up. If
it isn’t, press the button.
STEP 1
Plug the provided AUX 3.5mm audio cable into the TV’s AUX 3.5mm output
port, then plug the other end into the transmitter’s AUX 3.5mm port in the
“INPUT FROM TV” section.
AUX 3.5mm port
OPTION 2
NOTE: MostTVs support audio output through only one digital output
port at a time, so if your TV’s HDMI ARC port is in use, the optical port may
be disabled. You can either unplug the HDMI ARC device, or try connecting
the transmitter via RCA / AUX.
STEP 2
Check the transmitter’s audio signal indicators and ensure that “AUX” is lit up. If
it isn’t, press the button.
AUX
OPT
AUX
OPT
DC IN AUX AUX
OPTICAL OPTICAL
RX Output
To Speaker
TX Input
From TV
TV
AUX
