3. ANALYZER NOTES
• WARNING – THE ANALYZER’S ETHERNET CONTROLLER IS
FUNCTIONALLY A ETHERNET-TO-SERIAL ADAPTER AND THE BAUD RATE
IS FOR THE SERIAL SIDE. DO NOT CHANGE THE BAUD RATE FROM THE
FACTORY SETTING. IF YOU DO THE GUI WILL DISPLAY A “FAIL:GET START
PACKET ERROR.” MOST ANALYZERS REQUIRE A 115,200 BAUD RATE
EXCEPT FOR THE –SBS, -CLM, TRSA, AND –DRSA ANALYZERS WHICH
REQUIRE 230,400 BAUD RATE.
• Before the GUI can be used to remotely control PSA and MSA series spectrum analyzers you
must go into Menu 5 on the analyzer and either turn SCOM ON or REMOTE ON.
• If you see SCOM then you have the new ethernet hardware and will use the “LAN”
connection type discussed in Section 6.2.
• If you see REMOTE ON then you have what is known as a “SitePlayer” ethernet device
discussed in Section 6.3. SitePlayer devices were used in RSA and most PSA models until
June 2007, in the MSA-4570 until March 2008, and in the PSA-37XP until April 2008. The
networking capabilities of the SitePlayer are limited to direct ethernet connection with a
crossover cable and in small networks. Larger networks with more data traffic tend to cause
the SitePlayer to lockup. If you have a SitePlayer model, please call AVCOM to get your
analyzer upgraded to the new ethernet hardware.
** AVCOM GUI v2.8.5 and greater does not support SitePlayer type connections.
• A 9-wire serial cable is required if you are using serial connection type.
