6. SPECTRUM ANALYZER ETHERNET SETUP
6.1 SERIAL CONNECTION
Connect the spectrum analyzer directly to the user’s PC using the straight female-female DB-9 serial cable
provided. A 9-wire serial cable is required for operation. Under the “Control 1” tab of the GUI, select
“COM 1” from the “Spectrum Analyzer List” then Run to establish connection.
If a port other than COM 1 is being used, a new Serial Connection Profile will need to be added (see section
7.1).
6.2 ETHERNET CONNECTION
Connect the spectrum analyzer directly to the PCs ethernet port using a crossover ethernet cable or through a
switch or router with straight cables. The GUI contains a configuration tool for configuring the spectrum
analyzer’s ethernet settings under Configure>Ethernet Connection on the Main Menu. It allows ethernet
configuration directly or from within your LAN.
Ethernet configuration changes via both serial and ethernet are supported. A 9-wire serial cable is required
for operation.
6.2.1 ETHERNET CONFIGURATION
Use Configure>Ethernet Connection to open the ConfigTool and adjust the spectrum analyzer’s ethernet
controller’s parameters. Note that when ConfigTool first opens up the parameters shown are only the
default parameters and are not for any analyzer that you may be connected to! It is recommended that
you always do a Query and Import Current Settings before you make any changes!
To configure the spectrum analyzer via COM Port connection:
1. Select COM Port in Connection Type and input the applicable COM Port #. A 9-wire serial
cable is required for operation.
2. Select Query and Import Current Settings to pull in the parameters that are currently loaded in
the spectrum analyzer. Power cycle the SA when prompted to do so in the “Status” box.
3. Under Connection Settings, enter the new IP address and Port. Do not change the Baud Rate or
Serial Settings.
4. Select Save Settings to Analyzer. Power cycle the SA when prompted to do so in the “Status”
box.
To configure the spectrum analyzer via ethernet connection:
1. Select Ethernet in Connection Type.
2. If known, enter the IP of the SA you want to configure. Otherwise, select the network adapter from
