HARDWARE

The Front Panel

Revision 001 SNG-2500C User’s Guide 2-2

The following table explains each of the front panel controls:

Control Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

<UP> Button Scrolls the highlighting up through whatever menu is

currently displayed. If it is already at the top, the

highlighting wraps to the bottom of the menu. This button

is also used for toggling various menu options.

<SELECT> Button Selects the menu option that is currently highlighted. If no

menu is displayed, press the <SELECT> Button to display a

menu.

<DOWN> Button Scrolls the highlighting down through whatever menu is

currently displayed. If it is already at the bottom, the

highlighting wraps to the top of the menu. This button is

also used for toggling various menu options.

<BACK> Button Returns to the previously displayed menu. You can think

of the <BACK> Button as the opposite of the <SELECT>

Button.

<POWER> Button

and indicator

light

Press the <POWER> Button to apply power to the SNG-

2500C. Press it again to remove power. (If you can not

power the SNG-2500C down, hold the

<POWER> button in

for 10 seconds and it will shut down.) The red indicator

light is lit whenever the SNG-2500C has power.

<REFERENCE

LEVEL>

Button

and indicator

lights

Press the <REFERENCE LEVEL> Button to change the

reference level. The indicator lights show the new

reference level. If the reference level is too high, your

signal could be too strong to measure. If the reference level

is too low, your signal might not be visible at all.

<RBW>

(Resolution

Bandwidth)

Button and

indicator lights

Press the <RBW> Button to change the resolution

bandwidth. The indicator lights show the new RBW. Using

the proper resolution bandwidth makes it easier for you to

see smaller or larger signals.

Button and

indicator lights

Press the <RF INPUT> Button to change to a different RF

input. The indicator lights show which RF input is being

monitored.

<PRESET> Button When you have discovered the best settings for a particular

signal, you can save those settings as a preset. By saving

the settings for each signal that you monitor, you can create

a library of presets. Press the

<PRESET> button to cycle

through the presets.
