CONTROL 2
The Control 2 tab has several advanced control features.
1. Rotate - Shown at GUI startup and when connected to a SA with multiple inputs. Automatically
scrolls through the RF inputs that are selected.
2. RF Inputs - Select which RF Inputs you want to rotate through.
3. Rotate Interval - Sets how often the GUI will change the RF Input to the next RF Input selected.
4. Cross Polarization – Used to show the last RF Input signal (red waveform) along with the current
RF Input signal (white waveform) such as when tuning an antenna’s horizontal and vertical feeds.
May be used in conjunction with the 2dB Zoom option described below.
5. Center Frequency Sweep – When selected will automatically sweep the CF throughout its range.
When unselected will return the CF to the original point before Sweep started.
6. Frequency Step – Sets the CF step size taken during Sweep.
7. Sweep Interval – Sets how often the CF step is taken.
