AVer PTC500 - Page 49

44
Setting menu
Sub menu
2nd sub menu
Note
Video & Audio Setting
Video Output
3G-SDI 2: Panoramic
Auto
1080P/60
1080P/30
720P/60
Audio Input
Audio line in format:
G.711
IP Streaming Mode
Mode 1
PTZ Camera
Panoramic Camera
IP Streaming Mode
Mode 2
PTZ Camera
1080P/30
Panoramic Camera
1080P/30
Tracking Setting
(Teacher mode)
Mode
Teacher (default)
User can choose function
in this option.
Student
Tracking
Tracking on/off
Tracking on/off
Tracking
Select tracking zone (1
grid) set
Preview
Define the active zone.
Active zone is an area for
panoramic lens motion
detection. If you don’t set
it up. The default setting
is all the screen is active
zone.
Save
Tracking
Select shielded zone (8
grid) set
Preview
Define the shield zone.
Shield zone is an area
that you don’t want to
detect motion.
Save
+
Press + to add the new
area
-
Press - to eliminate the
existed area.
