English-5
RTMP:
Press
then to enable/disable the RTMP streaming function.
Long press either or button for 1~2 sec to turn on/off the fill light function.
When fill light is off, press / button to increase/decrease image brightness.
When fill light is on, press /
button to increase/decrease light level.
Installation
1. Connect VB130 to PC/laptop with provided USB 2.0 cable and connect the power cord of VB130 to
power wall outlet.
[Note] Use the supplied Velcro strap to secure and manage the cable.
Laptop
USB cable
Use USB type-A to
type-C adapter
for newer PC/Laptop.
or
+
2. Install wireless dongle. Plug it into the USB 2.0 type-A port. Use remote control or PTZApp 2 to
enable Bluetooth function. Enable Bluetooth of mobile phones to find VB130 and connect it to use
VB130 as external microphone and speaker during a conference meeting.
[Note] The wireless dongle is an optional item in certain countries. Regarding detailed settings of
Bluetooth, please refer to user’s manual.
To Next Page
