05/08 Rev. AB OPERATOR’S HANDBOOK Setup
9844/9854
2-15
Setting the Material Parameters
Use the following three parameters to set the material properties:
P Refer to the “Info-Printouts and Parameters” section on your CD-ROM for
more information on setting parameters.
Parameter Function
PRINT PARAMETERS/
Material type
Sets the material type (perforated or
endless)
PRINT PARAMETERS/
Material length
Sets the material length
PRINT PARAMETERS/
Material width
Sets the material width
SYSTEM PARAMETERS/
Light sens
. type
Sets the sensor type (reflex or transmission)
based on the material (marks or
perforations)
Tab. 1:Important parameters for setting the material properties.
