8
lever overhaul
5
Use a pick to disengage the return spring eyelet from the spring
anchor tab.
6
Turn the reach adjuster counter-clockwise until the adjuster
disengages from the pushrod.
Tooled reach adjust models: Use a 3 mm hex wrench to turn the
reach adjuster.
7
Remove the lever from the lever body.
8
Clamp a 2 mm hex wrench into a bench vise, with the tool
positioned vertically. Insert the lever body on the wrench through
the fluid flow port in the master cylinder head.
Place a clean rag under the lever body to wipe up any fluid
that may spill out.
Spring
anchor
tab
Return
spring
eyelet
2 mm
