Pendant Mount Adapter
1.
Orange ribs
Two orange-colored ribs that are used to align with the lanyard clip on the dome cover.
2. Lanyard to dome cover
Connects to the lanyard anchor on the dome cover.
3.
Cable entry hole
An entry hole for the cables required for camera operation.
4.
Lanyard anchor
The safety lanyard attaches to the anchor to prevent the adapter from falling during installation.
5. Lanyard to camera
Connects to the lanyard anchor on the camera base.
Pendant Mount Adapter 10
