AVL 9180 Service Manual

102
MAIN ASSEMBLY REAR
Item Part Description
1 BP5013 PANEL: ISE BACK COMPLETE (OLD COLOR)
1 BP5083 PANEL: ISE BACK COMPLETE (NEW COLOR)
2 BB5005 PC CARD: ISE SBC COMPLETE 9120/9130
2 BB5006 PC CARD: ISE SBC COMPLETE 9140
2 BB5015 PC CARD: ISE SBC COMPLETE 9180
3 US3059 PROGRAM SET: 9120 ENGLISH
3 US3060 PROGRAM SET: 9130 ENGLISH
3 US3061 PROGRAM SET: 9140 ENGLISH
3 US5010 PROGRAM SET: 9180
4 BB5007 PC CARD: ISE LAMP - 9120, 30, 40
4 BB5014 PC CARD: ISE LAMP - 9180
5 BP5007 SOLENOID: COMPLETE ISE
6 BP5002 MOTOR: ISE PERISTALTIC PUMP
7 BB5002 PC CARD: ISE DISPLAY COMPLETE - 9120, 30 , 40
7 BB5016 PC CARD: ISE DISPLAY COMPLETE - 9180
8 RE5025 SPACER: 50 DEGREE
9 DS5005 SCREW: #6 X .625"
10 DZ0488 WASHER: LOCK M4
11 EU1019 CONNECTOR: GROUND LUG
12 DS5006 SCREW: #6 X .375"
13 BP5003 PUMP ROLLER: ISE PERISTALTIC PUMP
14 DS5001 SCREW: 6-32 X .312"
15 DS5006 SCREW: #6 X .375"
16 DZ5000 WASHER: FLAT
17 DS5006 SCREW: #6 X .375"
18 DS0970 SCREW: PUMP MOTOR MOUNTING
19 DS5002 SCREW: SOLENOID VALVE MOUNTING
20 YB5002 SPRING PROBE: ELECTRODE CONNECTOR
