AVL 9180 Service Manual

2
2 General Description
Specifications
2.1 Reported Parameters Measuring Range Resolution
Whole Blood
Serum
Plasma
Sodium Na
+
40 - 205 mmol/L 0.1 mmol/L
Potassium K
+
1.5 - 15 mmol/L 0.01 mmol/L
(0.8 - 15 mmol/L dialysate)
Chloride Cl
-
50 - 200 mmol/L 0.1 mmol/L
Calcium Ca
++
0.2 - 5.0 mmol/L 0.01 mmol/L
Lithium Li
+
0.1 - 6.0 mmol/L 0.001 mmol/L
Urine
Sodium Na
+
1 - 300 mmol/L 1.0 mmol/L
Potassium K
+
4.5 - 120 mmol/L 0.1 mmol/L
(60 - 120 mmol/L w. addit. dilution)
Chloride Cl
-
1 - 300 mmol/L 1.0 mmol/L
Calcium and Lithium are not measured in urine samples.
Lithium is not measured in dialysate samples.
2.2 Operating Parameters
Sample type Whole blood, serum, plasma, urine,
dialysate (acetate or bicarbonate)
Sample device Syringe, sample cup, collection tube, capillary
Sample size 95 µL
Analysis time 50 seconds
Sample rate 45 per hour with printout
60 per hour without printout
