AVL 9180 Service Manual

104
NEEDLE UNIT ASSEMBLY
Item Part Description
0 BP5005 NEEDLE UNIT: COMPLETE MECHANISM
1 RE5011 PLATE: ISE NEEDLE UNIT RIGHT MOUNTING
2 RE5010 PLATE: ISE NEEDLE UNIT LEFT MOUNTING
3 RE5012 HOLDER: ISE NEEDLE UNIT PROBE
4 RE5014 GEAR: ISE NEEDLE UNIT
5 BP5018 LIGHT GATE: ISE NEEDLE UNIT COMPLETE
6 RE5029 PLUNGER: ISE NEEDLE UNIT
7 YB5001 SPRING: ISE NEEDLE UNIT
8 RE5028 ROD: ISE NEEDLE UNIT
9 RE5009 FLAP: ISE NEEDLE UNIT
10 BP5006 PROBE: ISE COMPLETE
11 BP9043 FILLPORT: ASSEMBLY
12 YA9023 PLATE: FILL PORT MOUNTING
13 DS5006 SCREW: #6 X 0.375"
14 DS5000 SCREW: #6 X .312
15 DZ0478 WASHER: FLAT M3
16 SS5003 TUBING: 3/8"OD X 1/4"ID CLEAR SILICON
17 YB5006 RUBBER STOP: ISE NEEDLE UNIT
