105

REAR PANEL ASSEMBLY

Item Part Description

0 BP5013 PANEL: ISE BACK COMPLETE (OLD COLOR)

0 BP5083 PANEL: ISE BACK COMPLETE (NEW COLOR)

1 BP5030 COVER: PAINTED ISE REAR (OLD COLOR)

1 BP5081 COVER: PAINTED ISE REAR (NEW COLOR)

2 BN5000 MODULE: SWITCHING ISE POWER SUPPLY

3 BK5000 RECEPTACLE: AC POWER WITH CABLE

4 EU5004 HOLDER: 2 POLE ISE FUSE

5 EV0044 FUSE: 1.6A SLOW

6 NS0025 SCREW PLASTIC TAPING

7 DS5000 SCREW: #6 X .312

8 EU1019 CONNECTOR: FASTON 6.3

9 BK5001 CABLE: DC ASSEMBLY

10 BK5012 CABLE: GROUND ASSEMBLY
