C.5 Serial IQ module pinouts
The following table lists the pinouts for the serial IQ module.
DB9-F PIN HOST SIGNAL NAME DESCRIPTION SIGNAL FLOW SRL SIGNAL NAME DESCRIPTION
1 DCD - Data Carrier Detect Out of SRL DTR - Data Terminal Ready
2 RXD - Receive Data Out of SRL TXD - Transmit Data
3 TXD - Transmit Data In to SRL RXD - Receive Data
4 DTR - Data Terminal Ready In to SRL DSR - Data Set Ready
5 GND - Signal Ground N/A GND - Signal Ground
6 DSR - Data Set Ready Out of SRL DTR - Data Terminal Ready
7 RTS - Request to Send In to SRL CTS - Clear to Send
8 CTS - Clear to Send Out of SRL RTS - Request to Send
9 N/C - Not Connected N/A N/C - Not Connected
Table A.3 Serial IQ Module Pinouts
Vertiv | Avocent® AutoView™ 2108/2216/3108/3216 Switch Installer/User Guide | 55
