avolta A015A-12C - Name of Parts; Accessories

13
4、Grip the carry handles located on either sides of the unit
and carefully lift until it slides out of the foam base.
5、Install the exhaust hose on the unit before operating the unit.
2. Name of Parts
1. Control panel
2. Air outlet
3. Hot air outlet
4. Air insertion (optional)
5. Drain hole
6. Filter
7. Cold Inlet
8. Hot Air inlet
Fig.1
3. Accessories
Part Description
Quantity
Main Air conditioner Unit
1
Hot air exhaust hose
1
Hose Connector (Window end)
1
Hose Connector (Air conditioner end)
1
Remote Controller
1
