PAGE 23
Windows PC Software
4 WINDOWS PC SOFTWARE
The configuration of the system is done by the Windows PC software in-
cluded in the delivery.
4.1 Hardware requirements
The PC must fulfil the following minimum requirements:
– IBM PC AT, IBM PS/2 or 100% compatible
– Pentium Processor (> 133 MHz) recommended
– Windows 95B/98/ME/2000/XP operating system
– approx. 600-kByte available conventional memory
– 2-MB available hard disk memory
– screen resolution of 800 x 600 pixels
– at least one available RS-232 serial interface
– Microsoft, IBM PS/2 or 100% software compatible mouse
4.2 Connection to the PC
Place the included disk in the disk drive and press the START button on Win-
dows 95B/98/ME/2000. Select the sub menu item Run...and insert into the
command line
<drive name:>setup.exe
(e.g. A:setup.exe).
Follow the instructions of the installation program.
Start the software after the installation, by clicking the TELEPHONE HY-
BRID symbol.
Connect the PC via a null modem cable (pin 2 and pin 3 are crossed, pin 5 =
GND) with the system.
Turn the system on.
The red blinking ALARM LED signals that the system is booting. After ap-
prox. 45 seconds the LED stops blinking. The system is ready for operation.
