Interfaces
A2.7.2 Analogue Audio Interfaces
The additional analogue audio interfaces on the module are available at a 15-
pole SUB-D socket. Optionally, an adapter cable with XLR sockets or plugs is
available.
A2.8 Receiver
The optional handset is connected here.
TAB. 17 PIN ASSIGNMENT: ANALOGUE AUDIO INTERFACES
Socket: HSD (SUB-D 15-pole)
Port Signal Electrical Characteristics
1 Channel 1
a
IN a
a On the AES/EBU audio interface, Channel 1 corresponds to the right channel
Input:
Rated Level: 0, +3, +6, +9 dBu
Impedance: > 15 kΩ
Output:
Rated level: 0, +3, +6, +9 dBu
Impedance: < 20 Ω
Head Room: 6 dB
2 Channel 1
a
IN b
3 Channel 2
b
IN a
b On the AES/EBU audio interface, Channel 2 corresponds to the left channel
4 Channel 2
b
IN b
5 Channel 1
a
OUT a
6 Channel 1
a
OUT b
7 Channel 2
b
OUT a
8 Channel 2
b
OUT b
9GND channel 1
a
IN
10 GND
11 GND channel 2
b
IN
12 GND
13 GND channel 1
a
OUT
14 GND
15 GND channel 2
b
OUT
NOTE An Analogue Adapter Cable SUB-D, 15-pole to XLR is available (ID:490090)
TAB. 18 PIN ASSIGNMENT: RECEIVER
RI11 Socket: handset(Western 4-pole)
Port Signal Electrical Characteristics
1Audio Out a
2Audio In a
3Audio In b
4Audio Out b
8
15
1
9
1 2 3 4
