AVT MAGIC - A1.2 Assignment with a Digital Input

PAGE 59
Audio-Interface assignment
A1.2 Assignment with a digital input
To use the digital input, the AES/EBU/Analogue Module must be fitted.
TAB. 8 AUDIO-INTERFACE ASSIGNMENT: DIGITAL INPUT
Individual Keypad Pre Talk Interface Assignment config.
no no no yes
no yes yes yes
yes no no no
yes yes no no
yes yes yes no
