APPENDIX 5 SPECIFICATIONS
48
APPENDIX 5 SPECIFICATIONS
Hardware
Video Input
One LAN port
Up to 6 Channels with a 6-port hub
Video Output HDMI
Video Output Resolution 1920 x 1080
Audio Output YES (Line Out / HDMI)
HDD Storage** 1 HDD
eSATA YES
USB Ports
Two on the rear panel:
one for video backup to USB flash drive, and
another for NVR control via a USB mouse
IR Remote Control YES
LAN port 1000Mbps
Ethernet
Internet port
10Mbps / 100Mbps
Software
Video Compression Format H.264
Local / Remote Display Mode 6 / 12CH
Local / Remote Playback Mode 6CH
Recording Mode Manual / Event / Alarm / Schedule
Recording Throughput**** 12CH Mode
Up to 360 IPS @ 720 x 480, 32 Mbps
Up to 120 IPS @ 1280 x 720, 32 Mbps
* Recording @ 1280 x 1024 or higher is only allowed for CH1
6CH Mode
Up to 180 IPS @ 720 x 480, 32 Mbps
Up to 180 IPS @ 1280 x 720, 32 Mbps
Up to 90 IPS @ 1920 x 1080, 32 Mbps
Pre-alarm Recording YES
Quick Search
Time / Motion / Alarm
Security Multiple user access levels with password
Remote Access
(1) Internet Explorer on Windows operating system
(2) EagleEyes on iPhone, iPad & Android mobile devices
(3) Our self-developed program, Video Viewer
Event Notification
Push Message / Push Video
General
Power Source (±10%) DC12V / 3A
Power Consumption < 9.5W (without a hard disk installed)
Operating Temperature 10 ~ 40 (50 ~104 )℃℃℉℉
Dimensions (mm)** 197(W) × 36(H) × 197(D)
Minimum PC Browsing Requirements
Pen‧ tium 4 CPU 1.3 GHz or higher, or equivalent AMD
256 MB RAM‧
AGP graphics card, Direct Draw, 32MB RAM‧
Windows ‧ 7, Vista & XP, DirectX 9.0 or later
Internet Explorer ‧ 7.x or later
Peripherals
(1) EoC converter
(2) HDMI Extender
(3) Video Server
* Specifications are subject to change without notice.
** Dimensional tolerance: ±5mm
