APPENDIX 2 BIT RATE TABLE FOR REFERENCE
The data below is for reference only.
The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the
complexity of your monitoring area, and how often the moving objects show in your monitoring area.
Testing Environment
Place: Office Entrance
Network translation: H.264
Camera type: Megapixel camera
Static: No one coming in and out Dynamic: One or two people coming in and out
Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps
SXGA Best FULL 3253 3216
High 2375 2160
Normal 1571 1266
Basic 1465 873
VGA Best 2010 1261
High 1042 1034
Normal 685 572
Basic 457 350
QVGA Best 646 366
High 482 350
Normal 302 286
Basic 168 161
SXGA Best 1/4 1163 1076
High 989 715
Normal 855 534
Basic 719 443
VGA Best 789 571
High 451 447
Normal 349 237
Basic 217 165
QVGA Best 269 147
High 182 131
Normal 164 113
Basic 97 71
